We Are DWS

DWS, Digital Wax Systems, was founded in Italy, in Vicenza, in 2007.

We already had a long experience in the prototyping sector. We develop hi-tech solutions for prototyping and high-speed production applied to reduce development times for new industrial products (time to market), systems that have become a strategic resource and must-have elements for corporate competitiveness.

MORE

Applications

Due to their reduced moving parts and unique user-friendliness, DigitalWax machines are characterised by high reliability and extra-low maintenance. A great flexibility is made possible by the quick material change, the absence of pre-heating and calibration.

Products

Digitalwax 008J

DESCRIPTION

DigitalWax 008 is an entry-level rapid prototyping system for jewellery applications.

With its unbeatable price-performance ratio and the lowest running cost in the market, DigitalWax 008 is the perfect choice for small companies with low volume production needs.

MAIN FEATURES

  • BluEdge® laser source
  • High accuracy
  • Direct casting
  • Master models for rubber moulds
  • The lowest running cost

Laser Source Solid State BluEdge BE-100
Scanning method Plotter X-Y
Working area (X,Y,Z) 65 x 65 x 90 mm
Slice thickness 0,01 – 0,10 mm
Laser Scanning speed 0-40 mm/sec
Software DigitalWax 008 Controller
OS compatibility Windows XP – Vista – 7
Input file format .stl – .slc
Machine size (X,Y,Z) 380 x 515 x 560 mm
Weight 45 Kg
Operating temperature range 22-25 °C
Operating humidity range 30-60 %
Electrical consumption 500 W
Power supply AC 230/115 V, 50/60 Hz


  • No. 1 Building platform mm 65×47 (working area mm 50×37)
  • No. 1 Resin tank mod. RT900
  • No. 1 Set of handling tools
  • No. 1 DigitalWax 009J Controller Software License
  • No. 1 User manual

IN DEPTH

DigitalWax 008 can build 2 to 10 models per day (24 hours), it depends on their size and complexity.
The three-dimensional models are built by a special laser which hardens a proprietary photo-curable resin.

The laser is specifically developed to guarantee high performance and long life.
Thanks to the layer-by-layer forming technology, there are no limits to the geometric complexity of the models: undercuts, cavities, thin surfaces and complex shapes can be created without any difficulty.
The BluEdge laser head allows the use of a new generation, high performance UV photo-curable resins for direct casting and rubber mould applications.

Digitalwax 009J

DESCRIPTION

Entry-level DLP® machine for jewelry industry.

Thanks to a productivity of up to 50 patterns per day, DigitalWax® 009J enters the entry-level product range with no compromises in terms of performance.

MAIN FEATURES

  • Led UV
  • High speed and accuracy
  • High surface quality
  • Direct casting
  • Master models for rubber moulds
  • No lamp replacement
  • No calibration

Laser Source LED UV
Scanning method DLP Texas Instruments Inc.
Working area (X,Y,Z) 50 x 37 x 100 mm
Slice thickness 0,01 – 0,10 mm
Software DigitalWax 009J Controller
OS compatibility Windows XP Pro – Vista – 7
Input file format .stl – .slc
Machine size (X,Y,Z) 315 x 335 x 630 mm
Weight 15 Kg
Operating temperature range 22-25 °C
Operating humidity range 30-60 %
Electrical consumption 150 W
Power supply AC 230/115 V, 50/60 Hz


  • No. 1 Building platform mm 75×75 (working area mm 65×65)
  • No. 1 Resin tank mod. RT800
  • No. 1 Set of handling tools
  • No. 1 DigitalWax 008 Controller Software License
  • No. 1 DigitalWax File Generator Software License
  • No. 1 Stl-Autoedit Software License
  • No. 1 User manual

IN DEPTH

DigitalWax® 009J is the lowest cost machine among the DigitalWax® products and it allows the highest accuracy and resolution thanks to the DLP® display technology developed by Texas Instruments®.
High speed and low running cost together with accuracy and resolution are the DWS essential features of this new product.
With a working area of 50×37 mm, DigitalWax® 009J is the ideal rapid prototyping choice with minimum investment and running costs. The extensive DigitalWax® J material portfolio is available, including the revolutionary Irix® Digital Stone.

Digitalwax 028J

DESCRIPTION

Desktop size system.
High speed rapid manufacturing solution for jewellery industry.

With its unbeatable price-performance ratio and the lowest running cost in the market, DigitalWax 028J is the perfect choice for fast production of high quality models.

MAIN FEATURES

  • BluEdge® laser source
  • High speed and accuracy
  • High surface quality
  • Direct casting
  • Master models for rubber moulds
  • No lamp replacement
  • No calibration

Laser Source Solid State BluEdge® BE-1500
Scanning method Galvanometer
Scanning speed 0 – 2200 mm/sec
Working area (X,Y,Z) 65 x 65 x 90 mm
Slice thickness 0,01 – 0,10 mm
Software DigitalWax 028J Controller
OS compatibility Windows 7
Input file format .stl – .slc
Machine size (X,Y,Z) 380 x 515 x 733 mm
Weight 50 Kg
Operating temperature range 22-25 °C
Operating humidity range 60 %
Electrical consumption 400 W
Power supply AC 230/115 V, 50/60 Hz


  • No. 1 Building platform mm 75×75 (working area: mm 65×65)
  • No. 1 Resin tank mod. RT800
  • No. 1 Set of handling tools
  • No. 1 Personal Computer with 19” LCD monitor
  • No. 1 UPS 650VA 230V 50/60 Hz
  • No. 1 DigitalWax 028J Controller Software License
  • No. 1 VisCAM Software License for DigitalWax, inclusive of VisCAM RP Setup (Module P04), RP Build (module P05), RP Hatch (module P06) and VisCAM, Mesh Repair (module P02)
  • No. 1 Stl-Autoedit Software License
  • No. 1 User manual

IN DEPTH

DigitalWax 028J can build up to 80 models per day (24 hours), it depends on their size and complexity.
The three-dimensional models are built by a special laser which hardens a proprietary photo-curable resin.
The laser is specifically developed to guarantee high performance and long life.
Thanks to the layer-by-layer forming technology, there are no limits to the geometric complexity of the models: undercuts, cavities, thin surfaces and complex shapes can be created without any difficulty.
The BluEdge® laser head allows the use of a new generation, high performance UV photo-curable resins for direct casting and rubber mould applications.

Digitalwax 028J Plus

DESCRIPTION

Desktop size system. High speed rapid manufacturing solution for jewellery industry.

With its unbeatable price-performance ratio and the lowest running cost in the market, DigitalWax 028J Plus is the perfect choice for fast production of high quality models.

MAIN FEATURES

  • BluEdge® laser source
  • High speed and accuracy
  • High surface quality
  • Direct casting
  • Master models for rubber moulds
  • No lamp replacement
  • No calibration

Laser Source Solid State BluEdge® BE-1500A/BE-1500AHR
Scanning method Galvanometer
Scanning speed 0 – 2200 mm/sec
Working area (X,Y,Z) 90 x 90 x 90 mm
Slice thickness 0,01 – 0,10 mm
Software DigitalWax 028J Controller
OS compatibility Windows 7
Input file format .stl – .slc
Machine size (X,Y,Z) 380 x 515 x 733 mm
Weight 56 Kg
Operating temperature range 22-25 °C
Operating humidity range 60 %
Electrical consumption 400 W
Power supply AC 230/115 V, 50/60 Hz


  • No. 1 Building platform mm 100×100 (working area: mm 90×90)
  • No. 1 Resin tank mod. RT800
  • No. 1 Set of handling tools
  • No. 1 Personal Computer with 19” LCD monitor
  • No. 1 UPS 650VA 230V 50/60 Hz
  • No. 1 DigitalWax 028J Software Suite License
  • No. 1 User manual

IN DEPTH

With its unbeatable price-performance ratio and the lowest running cost in the market, DigitalWax 028J Plus is the perfect choice for fast production of high quality models.
DigitalWax 028J Plus can build up to 150 models per day (24 hours), it depends on their size and complexity.
The three-dimensional models are built by a special laser which hardens a proprietary photo-curable resin.
The laser is specifically developed to guarantee high performance and long life.
Thanks to the layer-by-layer forming technology, there are no limits to the geometric complexity of the models: undercuts, cavities, thin surfaces and complex shapes can be created without any difficulty.
The BluEdge® laser head allows the use of a new generation, high performance UV photo-curable resins for direct casting and rubber mould applications.

Digitalwax 029J

DESCRIPTION

High speed rapid manufacturing solution for jewelry industry.

DigitalWax 029J is a rapid manufacturing system conceived to achieve the highest productivity and quality.

MAIN FEATURES

  • BluEdge® laser source
  • High speed and accuracy
  • High surface quality
  • Direct casting
  • Master models for rubber moulds
  • Extra-long life UV laser
  • No lamp replacement
  • No calibration
  • The lowest running cost

Laser Source Solid State BluEdge® BE-1700/BE-1700HR
Scanning method Galvanometer
Scanning speed 0 – 2600 mm/sec
Working area (X,Y,Z) 110 x 110 x 100 mm
Slice thickness 0,01 – 0,10 mm
Software DigitalWax 029J Controller
OS compatibility Windows 7
Input file format .stl – .slc
Machine size (X,Y,Z) 610 x 660 x 1400 mm
Weight 150 Kg
Operating temperature range 22-25 °C
Operating humidity range 30-60 %
Electrical consumption 500 W
Power supply AC 230/115 V, 50/60 Hz


  • N. 1 TTT system
  • N. 1 Building platform mm 138×138 (working area: mm 110×110)
  • N. 1 Resin tank mod. RT500
  • N. 1 Set of handling tools
  • N. 1 Personal Computer with LCD monitor
  • N. 1 UPS 650VA 230V 50/60 Hz
  • N. 1 DigitalWax 029J Software Suite License
  • N. 1 User manual

IN DEPTH

The unbeatable price-performance ratio and the lowest running cost in the market make DigitalWax 029J the perfect choice for medium and big companies, for service bureau oriented business and for all those who need to get models for direct casting and silicon rubber moulding, in large quantities and in a short working time.
DigitalWax 029J can build up to 270 models per day (24 hours), it depends on their size and complexity.
The three-dimensional models are built by a special laser which hardens a proprietary photo-curable resin. The laser head is specifically developed to guarantee high performance and long life.
Thanks to the layer-by-layer forming technology, there are no limits to the geometric complexity of the models: undercuts, cavities, thin surfaces and complex shapes can be created without any difficulty.
We offer high performance UV photo-curable resins for direct lost-wax casting and for rubber moulding.

Digitalwax 029J Plus

DESCRIPTION

High productivity rapid manufacturing solution for jewelry industry.

DigitalWax 029J Plus is a production-grade rapid manufacturing system conceived to achieve the highest productivity and quality.

MAIN FEATURES

  • BluEdge® laser source
  • TTT – Tank Translation Technology
  • Direct casting
  • High speed and accuracy
  • High surface quality
  • Master models for rubber moulds
  • No calibration
  • No lamp replacement
  • Extra-long life UV laser
  • Lowest running cost

Laser Source Solid State BluEdge® BE-1800/BE-1800HR
Scanning method Galvanometer
Scanning speed 5000 mm/sec
Working area (X,Y,Z) 150 x 150 x 100 mm
Slice thickness 0,01 – 0,10 mm
Software DigitalWax 029J Controller
OS compatibility Windows 7
Input file format .stl – .slc
Machine size (X,Y,Z) 610 x 660 x 1400 mm
Weight 150 Kg
Operating temperature range 22-25 °C
Operating humidity range 30-60 %
Electrical consumption 500 W
Power supply AC 230/115 V, 50/60 Hz


  • N. 1 TTT system
  • N. 1 Building platform mm 160×160 (working area: mm 150×150)
  • N. 1 Resin tank mod. RT500
  • N. 1 Set of handling tools
  • N. 1 Personal Computer with LCD monitor
  • N. 1 UPS 650VA 230V 50/60 Hz
  • N. 1 DigitalWax 029J Plus Software Suite License
  • N. 1 User manual




The TTT System (Tank Translation Technology) consists of an electromechanical device that automatically shifts the resin tank during the growing of the model: it allows to reduce the localized wear of the tank caused by the laser beam irradiation through the same area, improving both the life of the resin tank and the efficiency of the building process.

IN DEPTH

The large working area of 150×150 mm and the lowest running cost in the market make DigitalWax 029J Plus the perfect choice for medium and big companies, for service bureau oriented business and for all those who need to get models for direct casting and silicon rubber moulding, in large quantities and in a short working time.
DigitalWax 029J Plus can build up to 800 models per day (24 hours), it depends on their size and complexity. The three-dimensional models are built by a special laser which hardens a proprietary photo-curable resin. The laser head is specifically developed to guarantee high performance and long life.
Thanks to the layer-by-layer forming technology, there are no limits to the geometric complexity of the models: undercuts, cavities, thin
surfaces and complex shapes can be created without any difficulty.
We offer high performance UV photo-curable resins for direct lost-wax casting and for rubber moulding.

Digitalwax 030J

DESCRIPTION

High productivity rapid manufacturing system for jewellery industry.

DigitalWax® 030J rapid manufacturing system has been specifically developed for high productivity applications in the jewellery field.

MAIN FEATURES

  • BluEdge® laser source
  • TTT – Tank Translation Technology
  • Highest productivity
  • High speed and accuracy
  • Superior surface quality
  • Complete choice of materials
  • Lowest running cost

Laser Source Solid State BluEdge®
Working area (X,Y,Z) 300 x 300 x 300 mm
Machine size (X,Y,Z) 1150 x 1450 x 2100 mm



*Technical specifications subject to changes without notice.




The TTT System (Tank Translation Technology) consists of an electromechanical device that automatically shifts the resin tank during the growing of the model: it allows to reduce the localized wear of the tank caused by the laser beam irradiation through the same area, improving both the life of the resin tank and the efficiency of the building process.

IN DEPTH

High accuracy, large size capacity and the lowest running cost in the market are the main features of this innovative system.
In combination with a new generation of fully castable materials, DigitalWax 030J is the perfect solution for the mass production of wax-like patterns, delivering the highest accuracy and surface quality for a perfect replacement of the conventional mould injection method.
The great flexibility of the DigitalWax 030J allows a quick material change and a choice of different materials, either for direct casting and rubber moulding applications. Thanks to its long-term experience, DWS has developed the DC series of wax-based resins for direct casting and the DM series of hybrid materials for the production of master models for rubber moulding applications.

technology

X-Y Plotter

xyplotter


The Plotter X-Y scanning method is characterised by high accuracy and a relatively small productivity, the main features of the DigitalWax 008.

DLP Projection

dlp projection


The DLP Projection method is characterised by high accuracy and a high productivity, the main features of the DigitalWax 009J.

Galvanometer

galvanometer


The Galvanometer type scanning method allows the highest building speed and accuracy and is adopted by DigitalWax 020, 028, 029 and 030.


Discover more

Materials

DC Series

Resins for direct casting

DC casting resins are specifically designed for direct lost wax casting of jewelry models. Designed to allow the production of high-definition, detailed parts and smooth surfaces that do not require manual finishing. These products are ideal for special applications such as stone-in-place casting of resin models and filigrees.


Direct casting


DC100 Direct casting High accuracy, low shrinkage
DC300 Direct casting Wax-like, high growth factor
DC400 Direct casting Wax-like, high growth factor
DC500 Direct casting Wax-like, easy burnout
DC550 Direct casting Wax-like, smooth surface
DC600 Direct casting Wax-like, easy burnout



DM/DL Series

Resins for rubber moulds

DM/DL moulding resins have been designed for the creation of master models to be used in the production of rubber moulds, including VLT, liquid silicone and vulcanised rubber. These resins are suitable for thin models as well as thick ones, replacing traditional silver master models.


Rubber moulds

///
DM210RTV mouldingNano-filled ceramic, smooth surface
DM220HTV mouldingNano-filled ceramic, smooth surface
DL260RTV mouldingPlastic-like, ultra-smooth surface

IRIX

Biocompatible ‘digital stone’, available in all colours

Thanks to the nanotechnologies and the DWS patented additive manufacturing process, it is now possible to manufacture jewelry products using the innovative Irix® Digital Stone® material. A just-in-time production of the orders is made possible by Irix® Digital Stone®, allowing the expansion of the product range without investments in further production equipments.
Our customer will be able to order any customized colour according to the leading fashion trends. The creation of the stone is performed using nanotechnologies applied to the additive process, obtaining a biocompatible material having the main features of a natural stone.


IRIX


IRIX White Digital Stone® bio-compatible, Nano-filled ceramic, White colour
IRIX Black Digital Stone® bio-compatible, Nano-filled ceramic, Black colour
IRIX Ivory Digital Stone® bio-compatible, Nano-filled ceramic, Ivory colour
IRIX Coral Digital Stone® bio-compatible, Nano-filled ceramic, Coral colour
IRIX Turq Digital Stone® bio-compatible, Nano-filled ceramic, Turquoise colour



Technical data

Products

Digitalwax 020X

DESCRIPTION

DigitalWax 020X meets the strictest quality standards, reducing to a minimum or even doing away with the need to finish pieces.

All this in just a few hours thanks to a fast accurate laser and considerably lower consumption of photopolymerizable material.

MAIN FEATURES

  • Desktop size system
  • Quick material change
  • BlueEdge laser source
  • HIgh speed and accuracy
  • Long life UV laser
  • Low running cost

Laser Source Solid State BluEdge BE-1500C
Scanning method Galvanometer
Working area (X,Y,Z) 130 x 130 x 90 mm
Slice thickness 0,01 – 0,10 mm
Laser Scanning speed 0 – 2000 mm/sec
Software DigitalWax 020X Controller
OS compatibility Windows XP Professional
Input file format .stl – .slc
Network interface TCP/IP
Machine size (X,Y,Z) 380 x 515 x 810 mm
Weight 58 Kg
Operating temperature range 22-25 °C
Operating humidity range 30-60 %
Electrical consumption 400 W
Power supply AC 230/115 V, 50/60 Hz


  • No. 1 Building platform mm 138×138 (working area: mm 130×130)
  • No. 1 Resin tank mod. RT800
  • No. 1 Set of handling tools
  • No. 1 DigitalWax 020X Software Suite License
  • No. 1 User manual

galvanometer



The Galvanometer type scanning method allows the highest building speed and accuracy.

More about technology

IN DEPTH

All this in just a few hours thanks to a fast accurate laser and considerably lower consumption of photopolymerizable material, used without waste or the need for further support materials.

DigitalWax 020X is reliable, quiet and ideal for engineering, design, consumer products and for all sector in general that call for speed and accuracy in the new product development stage and manufacturing division. The flexibility of this product is guaranteed by the wide range of “X Series” materials, from which you can pick the most suitable for your requirements and business.

Digitalwax 029X

DESCRIPTION

DigitalWax 029X rapid manufacturing system has been specifically developed for high quality rapid manufacturing applications.

DigitalWax® 029X High accuracy, large size capacity and the lowest running cost in the market are the main features of this innovative system.

MAIN FEATURES

  • BluEdge® laser source
  • TTT – Tank Translation Technology
  • High speed and accuracy
  • High surface quality
  • Extra-long life UV laser
  • No lamp replacement
  • No calibration
  • Lowest running cost

Laser Source Solid State BluEdge BE-1800C
Scanning method Galvanometer
Working area (X,Y,Z) 150 x 150 x 200 mm
Slice thickness 0,01 – 0,10 mm
Laser Scanning speed 5000 mm/sec
Software DigitalWax 029X Controller
OS compatibility Windows XP Professional
Input file format .stl – .slc
Machine size (X,Y,Z) 610 x 660 x 1400 mm
Weight 150 Kg
Operating temperature range 22-25 °C
Operating humidity range 30-60 %
Electrical consumption 500 W
Power supply AC 230/115 V, 50/60 Hz


  • No. 1 Building platform mm 160×160 (working area: mm 150×150)
  • No. 1 Resin tank mod. RT500
  • No. 1 Set of handling tools
  • No. 1 Personal Computer with 19″ LCD monitor
  • No. 1 UPS 650VA 230V 50/60 Hz
  • No. 1 DigitalWax 029X Controller Software License
  • No. 1 DigitalWax 029X Software Suite
  • No. 1 User manual




The TTT System (Tank Translation Technology) consists of an electromechanical device that automatically shifts the resin tank during the growing of the model: it allows to reduce the localized wear of the tank caused by the laser beam irradiation through the same area, improving both the life of the resin tank and the efficiency of the building process.
galvanometer



The Galvanometer type scanning method allows the highest building speed and accuracy.

More about technology

IN DEPTH

Fully compatible with the majority of 3D CAD/CAM systems, DigitalWax 029X is the perfect solution either for rapid prototyping and rapid manufacturing of complex parts, delivering the highest level of accuracy and surface quality.
A quick 3D printout with high surface quality can be very helpful during the concept design phase: the DM210 ceramic nano-filled resin enables a designer to visually inspect the design for form, fit, and function.

Digitalwax 030X

DESCRIPTION

High-speed rapid manufacturing system for industrial design applications.

DigitalWax® 030X rapid manufacturing system has been specifically developed for high quality applications in the industrial design field.

MAIN FEATURES

  • BluEdge® laser source
  • High productivity
  • High speed and accuracy
  • Superior surface quality
  • Complete choiche of materials
  • The lowest running cost

Laser Source Solid State BluEdge
Working area (X,Y,Z) 300 x 300 x 300 mm
Machine size (X,Y,Z) 1100 x 700 x 2000 mm



*Technical specifications subject to changes without notice.

IN DEPTH

High accuracy, large size capacity (300x300x300 mm) and the lowest running cost in the market are the main features of this innovative system.
Fully compatible with the majority of 3D CAD/CAM systems, DigitalWax 030X is the perfect solution either for rapid prototyping and rapid manufacturing of eyewear parts, delivering the highest level of accuracy and surface quality.
A quick 3D printout with high surface quality can be very helpful during the concept design phase: the DM210 ceramic nano-filled resin enables a designer to visually inspect the design for form, fit, and function.
The new DL350 polypropylene-like resin has been specifically developed by DWS for flexible, fully functional prototypes.
DigitalWax 030X allows the production of lost wax casting products as well by a simple and quick material change. Thanks to its long-term experience, DWS has developed the DC resin series for direct casting of glasses parts, which includes three different solutions for a full coverage of the casting applications.

Materials

DC Series

Resins for direct casting

DC casting resins are specifically designed for direct lost wax casting applications.





DC100 Direct casting High accuracy, low shrinkage
DC500 Direct casting Wax-like, easy burnout

DL Series

Resins for rubber moulds

DL resins have been developed for rapid prototyping and rapid manufacturing of functional parts.


flexibility


/

DL260 Functional parts Plastic-like, ultra-smooth surface
DL350 Functional parts Polypropylene-like
DL360 Functional parts Transparent – Strong

DM Series

DM nano-filled resins are the right materials for heat resistant parts with high accuracy and excellent surface quality.





DM210 Concept modelling Ceramic-like, high surface quality, > 90°C
DM220 Concept modelling Nano-filled ceramic, smooth surface, > 180°C

Samples

Some samples produced with the DWS technology.

Drill part

Drill part

Surgical Guides

Surgical Guides

Turbine

Turbine

Ring

Ring

Direct casting

Direct casting

Rings

Rings

Micropave

Micropave

Badges

Badges
